Mini Skid Steer Loader XCMG XC760K
Technical documentation
DESCRIPTION
CHARACTERISTICS
Mini Skid Steer Loader XCMG XC760K
XCMG Chinese 1 ton Cheap Mini Skid Steer Snow Removal Loader XC760K.
XC760K with strong power and rich attachments, the XCMG skid-steer loader can better adapt to the operations in narrow space and is an ideal tool for road construction, municipal maintenance, port handling, garden maintenance, and pasture production, featuring low operation cost and remarkable economic benefits.
Advantages and Highlights:
- Strong and Efficient Power Transmission System
* Features strong power, ultra-low emission, and higher fuel efficiency.
* Features stable drive and high efficiency and reliability.
* Feature automatic lubrication and maintenance-free.
- Solid and Reliable Design
* Adopted features compact structure and high firmness and reliability.
* Realize reasonable stress distribution.
- Flexible Operations
* Prevent scattering of material and improve working efficiency.
- Incomparable Multi-Functionalities
* Enables the change of tens of attachments, including sweeper, planer, breaking hammer, and ditcher, rapidly and conveniently.
|
Product description:
|
Block
|
XC760K
|
|||
|
Rated load
|
Kg
|
1080
|
|||
|
Console End Load
|
Kg
|
2160
|
|||
|
Operating weight
|
Kg
|
3450
|
3700
|
3650
|
|
|
Maximum switching force
|
KN
|
22
|
|||
|
Engine
|
Manufacturer
|
YANMAR mini excavator
|
Weichai
|
||
|
Model
|
4TNV98T
|
WP4G80E231
|
WP4.1G82E301
|
||
|
Rated power
|
HP/kW
|
82.2/61.3
|
80/60
|
80/60
|
|
|
Rated speed
|
RPM
|
2500
|
2300
|
2400
|
|
|
Cooling mode
|
Water cooling
|
||||
|
performance parameter
|
Working mode
|
Hydraulic Pilot and Electronic Multi-Function
|
|||
|
Standard
|
12-16.5
|
||||
|
Max Speed
|
km/h
|
12.5
|
|||
|
Max working height
|
Mm
|
4180
|
|||
|
Bucket hinge height
|
Mm
|
3205
|
|||
|
Cab top height
|
Mm
|
1960
|
|||
|
Maximum horizontal height bucket bottom
|
Mm
|
2997
|
|||
|
Length without bucket
|
Mm
|
2660
|
|||
|
Length with bucket
|
Mm
|
3610
|
|||
|
overthrow the corner
|
°
|
40
|
|||
|
Maximum dumping height
|
Mm
|
2450
|
|||
|
First-bucket corner
|
°
|
thirty
|
|||
|
Bucket angle at the highest point
|
°
|
83
|
|||
|
unloading distance
|
Mm
|
570
|
|||
|
Wheelbase
|
Mm
|
1188
|
|||
|
exit angle
|
°
|
25
|
|||
|
Ground clearance
|
Mm
|
205
|
|||
|
wheel track
|
Mm
|
1500
|
|||
|
Bucket capacity (stacking height)
|
M³
|
0.6
|
|||
|
Bucket capacity (per cage measured loose)
|
M³
|
0.47
|
|||
|
Diesel tank capacity
|
L
|
95
|
|||
|
Container Storage Container for Hydraulic Lubricating Oil
|
L
|
70
|
|||
